Molybdenum Rod Manufacturer, Molybdenum Round Bar Supplier, ASME SA287 Molybdenum Round Bar Manufacturer, ASTM A387 Alloy Rod Exporter, Molybdenum Rod Manufacturer in Pune
Molybdenum Products is a leading Molybdenum Rod Manufacturer In Pune known for offering materials to aerospace, automotive & energy industries. Pune-based companies alone, being as a Molybdenum Rod Manufacturer the two products are Molybdenum rods and bars with international quality standard. These Molybdenum Rod are used in the market due to their optimum Toughness & Stability, We have supplied and exported our Molybdenum Bar all across the Globe and many countries have identified Pune as an outstanding place for manufacturing.
The Pune based manufacturers make sure that these Molybdenum Round Bars are in accordance with the international industrial standards and are best suitable for all the applications. By such technologies employed by them and the insistence on quality, they still uphold the reputation of Pune as the Manufacturer of industrial materials globally.
ASTM A387 Alloy Steel Round Bars, Molybdenum Rods Manufacturers, Molybdenum Mo-1 Bar, ASTM B387 Mo-1 Rod, Molybdenum Rod Manufacturer in Pune
Molybdenum Products is one of the trustworthy Molybdenum Rod Manufacturers and Supplier in Pune. Products Starts from difficult ASTM A387 Alloy Rods to ASME SA287 Molybdenum Round Bars, These products had been established to serve the necessity within the diversified industries. Pune based Molybdenum Rod Manufacturers ensure that its supplies are of the highest quality that viable projects in the state, and in the larger market benefit from. We are also well known as Molybdenum Sheet Manufacturers India.
Molybdenum Rod Specification Table
| Product | Molybdenum Rod |
| Standard | ASTM B387, Type 361/364 |
| Process | Drawing, swaging |
| Purity | Mo≥99.95% |
| Size | 0.16”~6.0” diameter x L |
| Surface | Grinding, Finish turning, Black Oxide, Chemically clneaned |
Molybdenum Rod Manufacturer – Types
Molybdenum Rod Manufacturer – Size Chart
| Diameter[mm] | Length[mm] | Weight[kg] |
| 2.000 | 500 – 3.000 | 0.032 |
| 3.00 | 500 – 3.000 | 0.072 |
| 3.175 | 500 – 3.000 | 0.081 |
| 4.000 | 500 – 3.000 | 0.128 |
| 4.750 | 500 – 3.000 | 0.181 |
| 5.000 | 500 – 3.000 | 0.200 |
| 6.000 | 500 – 3.000 | 0.288 |
| 6.350 | 500 – 3.000 | 0.323 |
| 7.000 | 500 – 3.000 | 0.392 |
| 7.925 | 500 – 3.000 | 0.503 |
| 8.000 | 500 – 3.000 | 0.512 |
| 9.000 | 500 – 3.000 | 0.649 |
| 9.525 | 500 – 3.000 | 0.726 |
| 9.525 | 500 – 3.000 | 0.726 |
| 10.000 | 500 – 3.000 | 0.801 |
| 12.000 | 500 – 2.000 | 1.153 |
| 12.000 | 500 – 2.500 | 1.153 |
| 12.700 | 500 – 2.000 | 1.291 |
| 12.700 | 500 – 2.000 | 1.291 |
| 13.000 | 500 – 2.000 | 1.353 |
Properties of Molybdenum Rod Manufacturer
| Molecular Weight | 95.94 |
| Appearance | Silvery |
| Melting Point | 2623 °C |
| Boiling Point | 4639 °C |
| Density | 10280 kg/m3 |
| Solubility in H2O | N/A |
| Electrical Resistivity | 5.2 microhm-cm @ 0 °C |
| Electronegativity | 1.9 Paulings |
| Heat of Fusion | 6.6 Cal/gm mole |
| Heat of Vaporization | 128 K-Cal/gm atom at 4612 °C |
| Poisson’s Ratio | 0.31 |
| Specific Heat | 0.0599 Cal/g/K @ 25 °C |
| Tensile Strength | N/A |
| Thermal Conductivity | 1.38 W/cm/K @ 298.2 K |
| Thermal Expansion | (25 °C) 4.8 µm·m-1·K-1 |
| Vickers Hardness | 1530 MPa |
| Young’s Modulus | 329 GPa |
Chemical Composition Of Molybdenum Rod Manufacturer
Grade |
The impurity content is not more than % | |||||||
| Fe | Ni | Al | Si | Mg | C | N | O | |
| Mo-1 | 0.01 | 0.005 | 0.002 | 0.01 | 0.005 | 0.01 | 0.003 | 0.008 |
| Mo-2 | 0.01 | 0.005 | 0.005 | 0.01 | 0.005 | 0.01 | 0.003 | 0.02 |
Mo Bar
| Diameter (inch) | Length (inch) | Diameter Tolerance (inch) | Length Tolerance (inch) |
| 0.08 – 0.40 | <315 | ±0.005 | +0.08, -0 |
| 0.40 – 0.80 | <118 | ±0.010 | +0.08, -0 |
| 0.80 – 4.00 | <78 | ±0.015 | +0.08″, -0 |
| >4.00 | <40 | ±0.025 | +0.08, -0 |
Mechanical Characteristics of Molybdenum Rod
| Tensile Strength | KSI (MPa)-RT | 150 (1034) |
| KSI (MPa)-500°C | 75 (517) | |
| KSI (MPa)-1000°C | 25 (172) | |
| Elongation | % in 1.0″. | 12 |
| Typical Hardness | HV10 | >220 |
| Modules of Elasticity | GPa | 320 |
Molybdenum Bar’s Composition Standard
| Molybdenum Chemistry |
| Minimum % 99.97 |
Standard Molybdenum Alloy Steel Rod
| MO007900 | Diameter:6.0mm, Purity:99.9%, Condition:Centreless ground |
| MO007901 | Diameter:3.0mm, Purity:99.9%, Condition:Centreless ground |
| MO007902 | Diameter:1.5mm, Purity:99.9%, Condition:Centreless ground |
| MO007903 | Diameter:2.0mm, Purity:99.9%, Condition:Centreless ground |
| MO007904 | Diameter:4.0mm, Purity:99.9%, Condition:Centreless ground |
| MO007905 | Diameter:5.0mm, Purity:99.9%, Condition:Centreless ground |
| MO007906 | Diameter:5.0mm, Purity:99.98% |
| MO007907 | Diameter:3.5mm, Purity:99.9%, Condition:Centreless ground |
| MO007908 | Diameter:1.25mm, Purity:99.9%, Condition:Centreless ground |
| MO007910 | Diameter:8.0mm, Purity:99.9%, Condition:Centreless ground |
| MO007920 | Diameter:10.0mm, Purity:99.9%, Condition:Centreless ground |
| MO007922 | Diameter:12mm, Purity:99.9%, Condition:Centreless ground |
| MO007926 | Diameter:15.0mm, Purity:99.9%, Condition:Centreless ground |
| MO007931 | Diameter:20.0mm, Purity:99.9%, Condition:Centreless ground |
| MO007945 | Diameter:25mm, Purity:99.9%, Condition:Centreless ground |
| MO007950 | Diameter:30mm, Purity:99.9%, Condition:Centreless ground |
| MO007960 | Diameter:50mm, Purity:99.9%, Condition:Centreless ground |
| MO007975 | Diameter:75mm, Purity:99.9%, Condition:Centreless ground |
| MO007995 | Diameter:100mm, Purity:99.9%, Condition:Centreless ground |
Molybdenum Bars Thermal Properties
| Properties | Metric | Imperial |
| Thermal expansion coefficient (@20°C/68°F) | 5.35 µm/m°C | 2.97 µin/in°F |
| Thermal conductivity | 138 W/mK | 958 BTU in/hr.ft².°F |
Chemical Composition Of ASTM A240 SS J4 Molybdenum Rod
Grade |
The impurity content is not more than % | |||||||
| Fe | Ni | Al | Si | Mg | C | N | O | |
| Mo-1 | 0.01 | 0.005 | 0.002 | 0.01 | 0.005 | 0.01 | 0.003 | 0.008 |
| Mo-2 | 0.01 | 0.005 | 0.005 | 0.01 | 0.005 | 0.01 | 0.003 | 0.02 |
Bars’s Made Of Titanium-Zirconium-Molybdenum (TZM)
| Diameter[mm] | Length[mm] | Quality | Weight[kg] |
| 4.750 | 500 – 3.000 | ground | 0.181 |
| 6.000 | 500 – 3.000 | ground | 0.288 |
| 6.350 | 500 – 3.000 | ground | 0.323 |
| 8.000 | 500 – 3.000 | ground | 0.512 |
| 10.000 | 500 – 3.000 | ground | 0.801 |
| 12.700 | 500 – 2.000 | forged | 1.291 |
| 15.875 | 500 – 2.000 | ground | 2.018 |
| 16.000 | 500 – 1.600 | forged | 2.05 |
| 18.000 | 500 – 2.000 | forged | 2.594 |
| 19.050 | 500 – 1.500 | ground | 2.906 |
| 20.000 | 500 – 2.000 | forged | 3.203 |
Molybdenum Round Bars Standard Length Tolerances (Inches)
| Diameter | .5″ to 12″ | 12″ to 24″ | > 24″ |
| .020 to .100 | ± .010 | ± .015 | ± .0625 |
| .100 – .500 | ± .015 | ± .015 | ± .0625 |
| .500 to 1.000 | ± .015 | ± .030 | ± .0625 |
| 1.000 to 1.500 | ± .030 | ± .0625 | ± .0625 |
ASTM A387 Molybdenum Rod Standard Diameter Tolerances (Inches)
| Diameter | Black/Clean | Ground |
| .020 to .025 | ± .001 | ± .001 |
| .025 to .070 | ± .0015 | ± .001 |
| .070 to .200 | ± .002 | ± .001 |
| .200 to .250 | ± .007 | ± .001 |
| .250 to .437 | ± .007 | ± .0015 |
| .437 to .750 | ± .010 | ± .003 |
| .750 to 1.000 | ± .015 | ± .005 |
| 1.000 to 1.250 | ± .015 | ± .005 |
| 1.250 to 1.750 | ± .025 | ± .005 |
Application of Molybdenum Rod
- Construction
- Automotive
- Aerospace
- Oil and Gas
- Chemical Processing
- Food and Beverage Industry
- Medical and Pharmaceutical
- Energy Sector
Packing of Molybdenum Rod and Bar
Each order is further processed based on the customer’ s specifications, including packing for exports like wooden case, pallet or as per the customer’s need.
- Wooden Boxes
- Jute Bags
- Shrink Wrap
- Carton Boxes
Most Popular Types Of Pure Molybdenum Bar
| Molybdenum Welding Rod in Pune | ASTM A387 Alloy Steel Rod in Pune |
| ASME SA387 Alloy Steel Rod in Pune | Molybdenum Round Bars in Pune |
| Molybdenum Flat Bar in Pune | ASME SA387 Molybdenum Rods in Pune |
| Molybdenum Threaded Rod in Pune | Pure Molybdenum Bar in Pune |
| Molybdenum Square Bar in Pune | Silicon Molybdenum Rod in Pune |
| Molybdenum Type 365 Bright Bar in Pune | A387 Molybdenum Rod in Pune |
| Molybdenum Barrier Metal in Pune | Molybdenum Carbide Rods in Pune |
| ASTM A387 Alloy Steel Round Bars in Pune | ASME SA387 Molybdenum Round Bars in Pune |
| Molybdenum Silicon Rods in Pune | SA387 Molybdenum Round Bars in Pune |
| Molybdenum Rods in Pune | Molybdenum Threaded Rods in Pune |
| Molybdenum Carbide Rods in Pune | Molybdenum Bars in Pune |
| ASTM A387 Alloy Steel Rods in Pune | Molybdenum Square Bar in Pune |
Molybdenum Rod Manufacturers in Pune
At Molybdenum Products, we are approved Pure Molybdenum Rods Manufacturer and Supplier in Mumbai, Chennai, Indore, and other cities in India. Our clients are increasing daily, so we supply large quantities of ASTM A387 Alloy Steel Rod to new cities monthly to address industrial demands. These strength make us the leading SA387 Molybdenum Round Bars dealers in Pune.
