Beryllium Copper C17200 HR Strip Exporter in Mumbai, C17200 Copper Beryllium Alloy Strip Manufacturer, UNS C17200 Strip, Beryllium Copper Alloy 25 Strip Suppliers and Stockist, Beryllium Copper C17200 Strip Manufacturer in India
C17200 Beryllium Copper Strips are also available in various types such as CDA 172 Strips, Alloy 25 Strips, or DIN 2.1247 Strips are manufactured from best-grade ASTM B194 Copper Beryllium. These Strips are preferred because they offer high strength, tolerance, and electrical and thermal conductivity and are suitable for diversified sectors including aerospace, electronics, automobile, and other engineering sectors. These Beryllium Copper UNS C17200 Strips are all available in standard widths measuring between 0.05 mm to 3 mm widths, and 610 mm widths, depending on the thickness, and can be cut accurately to the client's required length. BeCu C17200 Strip Supplier and Exporter provide specifications of exact dimensions, uniform surfaces, and strips that are manufactured for usage in high-performance applications. Molybdenum Products is a well-known brand for Beryllium Copper C17200 Strips manufacturers in India.
Beryllium Copper C17200 Strip Specification Table
| Property | Specification |
| Material | Beryllium Copper C17200 |
| Thickness | 0.02 mm to 6.00 mm |
| Width | 10 mm to 400 mm |
| Temper | Soft, Quarter Hard, Half Hard, Full Hard |
| Surface Finish | Bright, Matte, Mill Finish |
| Tensile Strength | 1100 MPa (Max) |
| Hardness | Rockwell B90 to C45 |
| Applications | Electrical Contacts, Springs, Connectors |
Chemical Composition Of Beryllium Copper C17200 Strip
| Element | Composition (%) |
| Beryllium (Be) | 1.80 - 2.00 |
| Copper (Cu) | Balance |
| Cobalt + Nickel (Co + Ni) | 0.20 min |
| Iron (Fe) | 0.10 max |
| Aluminum (Al) | 0.20 max |
| Silicon (Si) | 0.20 max |
| Other Elements | 0.50 max |
Mechanical Characteristics of Beryllium Copper C17200 Strip
| Property | Value |
| Tensile Strength | 1100 MPa (Max) |
| Yield Strength | 690 MPa (Typical) |
| Elongation | 10% - 15% |
| Modulus of Elasticity | 128 GPa |
| Hardness | Rockwell B90 - C45 |
| Thermal Conductivity | 105 W/m·K |
| Electrical Conductivity | 22% IACS (International Annealed Copper Standard) |
Application of Beryllium Copper
- Construction
- Automotive
- Aerospace
- Oil and Gas
- Chemical Processing
- Food and Beverage Industry
- Medical and Pharmaceutical
- Energy Sector
Packing of Beryllium Copper
Each order is further processed based on the customer’ s specifications, including packing for exports like wooden case, pallet or as per the customer’s need.
- Wooden Boxes
- Shrink Wrap
- Jute Bags
- Carton Boxes
Most Popular Types Of Beryllium Copper C17200 Strip
| Type | Applications |
| Beryllium Copper Hardened Strip | Electrical connectors, switches, and relay components |
| Cold Rolled Beryllium Copper Strip | Springs, washers, and industrial gaskets |
| Precision Beryllium Copper Strip | Telecommunication devices and precision instruments |
| Beryllium Copper Alloy Strip | Automotive electronics and aerospace parts |
| Corrosion-Resistant Beryllium Copper Strip | Marine environments and chemical processing equipment |
| High-Conductivity Beryllium Copper Strip | Electrical circuits and heat exchangers |
Beryllium Copper C17200 Strip Manufacturer and Supplier in Indian Cities
Beryllium Copper C17200 Strip Suppliers in India, USA, Middle East and Europe
Molybdenum Products is a Certified Pure Beryllium Copper C17200 Strip Supplier and Exporter in India, UAE, USA, Africa, Europe, and other global regions. Our clients are increasing daily, so we export plenty of Beryllium Copper Alloy Strip to new ports monthly to address global demands. These strength make us the leading Beryllium Copper Alloy Strip Dealers in India.
